M12 Channel Nut Stainless Steel 316 A4-70 Spring Channel Nuts

Brand Name : PM

Model Number : M5-M12,1/4-1/2

Certification : ISO

Place of Origin : CHINA

MOQ : 10PCS

Price : USD 0.0015-2 PER PCS

Payment Terms : L/C, T/T

Supply Ability : 500tons per month

Delivery Time : 15-25DAYS PER CONTAINER

Packaging Details : 25kgs/carton and 36 cartons on standard export wooden pallets

Standard : ASME/ANSI ,DIN

Size : M12

Surface : Plain

Material : Stainless steel 316

Grade : A4-70

Thread : UNC

Sample : 10pcs free

Product name : Stainless steel 316 A4-70 spring channel nut M12

Contact Now

Stainless steel 316 A4-70 spring channel nut M12

We offer a wide array of channel strut products and strut accessories to complement its channel tray systems, and includes all standard strut products. Strut is used in various industries as light structural support for tray systems and other mechanical components.

M12 Channel Nut Stainless Steel 316 A4-70 Spring Channel Nuts

Standard: ASME/ANSI ,DIN

Size: 1/4",5/16",3/8",1/2", M6-M18

Material: Carbon Steel, Stainless Steel

Grade: Class 4/6 SAE J429 Gr.2, B8,B8M,B8T

Thread: UNC, UNF,UN

Finish: Plain, Zinc Plated(Clear/Blue/Yellow/Black), Black oxide, Nickel, Chrome, H.D.G.

Type:
with standard spring(Spring length : 40 mm)
with long spring(Spring length : 60 mm)
with short spring(Spring length : 20 mm)
with out spring
with stud(stud length are available)

M6x34.5(length)x19(width)x6(thickness)
M8X34.5(length)X19(width)X6(thickness)
M10X34.5(length)X19(width)X8(thickness)
M12X34.5(length)X19(width)X9.1(thickness)
spring length: 38-40mm

Packaging Details: a. bulk in cartons (<=25kg )+ 36CTN/wood solid Pallet

b. bulk in cartons 9"x9"x5" (<=18kg )+ 48CTN/wood solid Pallet

Supply Ability:1000 tons per month

MinimumOrder:200kgs for each specification

Trade Term:FOB/CIF/CFR/CNF/EXW/DDU/DDP

Payment :T/T, L/C , D/A , D/P , Western Union,etc

Market:South&north Amrica/Europe/ etc.
